Jiaxing Towex New Materials Co., Ltd. is one of the most reliable manufacturers and suppliers of uhmwpe ud fabric in China, featured by quality products and low price. Please rest assured to wholesale bulk uhmwpe ud fabric in stock here and get quotation from our factory. Customized orders are welcome.
TOWEX UHMWPE Woven Series is engineered for applications where extreme cut resistance, durability, and multi-hit ballistic integrity are paramount. Unlike standard UD (Unidirectional) materials, our woven fabrics utilize a high-tenacity interlocking structure that provides superior mechanical protection and structural stability.
Product Comparison & Layer Estimation Table
This table correlates fiber denier, fabric density, and the estimated layers required to meet international safety standards.
|
Fabric Model |
Fiber Denier (D) |
Areal Density (g/m2) |
Weave Pattern |
NIJ IIIA Layers (Est.) |
Primary Application |
|
TW-150-P |
400D / 600D |
150 |
Plain |
42 - 48 |
VIP Concealable Vests, EOD Suits,Bulletproof Umbrella |
|
TW-220-D |
800D / 1000D |
220 |
Plain / Twill |
32 - 38 |
Tactical Apparel, Police Uniforms,Bulletproof Bag |
|
TW-380-T |
1200D / 1600D |
380 |
Twill |
22 - 28 |
Spall Liners, Ballistic Blankets,Bulletproof Door |
|
TW-500-B |
2400D / 3000D |
500 |
Basket |
Hybrid Layer |
Square Blast Shield,Armored vehicle |
Core Technical Advantages
Superior Cut & Abrasion Resistance
The mechanical interlocking of the weave makes it nearly impossible for blades to penetrate, achieving EN388 Level 5 protection.
Zero-Resin Flexibility
Unlike UD sheets, our woven series contains no adhesives, offering maximum breathability and "Soft-Touch" comfort for next-to-skin tactical wear.
Exceptional Multi-Hit Capability
The woven matrix maintains structural integrity even after multiple impacts, preventing large-scale unraveling at the strike point.
Surface Treatment Technology
Every TOWEX woven roll undergoes Plasma Treatment to minimize fiber slippage and ensure consistent performance during high-speed automated cutting.
Key Comparison: Woven vs. UD (Unidirectional)
|
Feature |
TOWEX Woven Series |
TOWEX UD Series |
|
Ballistic V50 |
High Performance |
Industry Leading |
|
Cut/Slash Resistance |
Superior (Physical Lock) |
Moderate (Fiber Displacement) |
|
Durability (Flex-Life) |
Extreme (Rugged) |
Moderate (Delamination Risk) |
|
Processing |
Easy to Sew & Tailor |
Best for Lamination/Molding |
|
Tactical Use |
Hybrid Vests, Bulletproof Vehicle Lining |
Bulletproof vests, bulletproof helmets, bulletproof armor plates |
Why Choose TOWEX as Your Source Manufacturer?
As a Source Factory, TOWEX eliminates the middleman, offering:
Direct B2B Pricing
Competitive rates for global ballistic and industrial tenders.
Custom Weave Development
Tailored GSM, width, and weave patterns (Plain, Twill, Satin, Basket).
Standard Compliance
Fully tested for NIJ 0101.06, EN388, and GA141 compliance.
Global Logistics
Professional handling of high-performance fiber exports to 50+ countries.
Product qualification
Our Certificate
We are Direct Manufacturer
Export Strength proves trustworthiness
Hot Tags: UHMWPE ud fabric, China UHMWPE ud fabric manufacturers, suppliers, factory
